Model | EMV033M |
sensor | 1/3” 960P Megapixel CMOS AHD
|
Effective Pixels | 960P 1.3 Megapixel |
Signal system | PAL/NTSC |
Horizontal resolution | 960P |
minimum illumination | 0lux/F1.2 (LED ON) |
Audio | Without Audio |
lens | F=2.1mm/2.8mm/3.6mm |
SNR | ≥50dB |
Shutter speed | PAL:1/50 s -1/100.000 s, NTSC : 1/60s – 1/100.000 s |
W/B | ATW |
IR wavelength | 850nm |
IR light | No |
Distance | 10m-15m |
Video output | 1Vp-p,75 ohm, BNC |
Power supply | DC 12V ± 10% |
Working temperature | -10℃~+50℃ |
Waterproof grade | IP66 |
Dimension | 50mm x 44mm x 32mm |
Weight | 0.35Kgs |
Feature:
*Sensor: 1.3 Megapixel 960P AHD
*Lens: 2.1mm/2.8mm/3.6mm
*Lens Angle: 120°/90°
*Audio: Without audio( With Audio optional)
*No IR
*Shell material: aluminum alloy
*Bracket material: iron
*Dustproof, waterproof, hydrochloric acid prevention, explosion prevention
