● Embedded compact design, low power, high efficient H.264 compress, high reliability.
● 4CH 720P HD recording, supports 2TB hard disk & 128GB SD card.
● Optional 3G/4G, GPS, WIFI functions.
● Built-in G-sensor.
● Data protection when in sudden power off, optional inside-laid UPS battery.
● Rich external ports, incl. 2x RS232, 2x RS485, 8x alarm in & 2x alarm out ports, VGA etc.
● Auto image switch of car left/right turning, backing change.
● With a simple hard disk installation and a good and reliable anti-shake protection system.
● Directly mouse controlled menu entering.
● Export of video recordings directly via USB port.
● CMS platform ability for big fleet and user management.
● Simple easy to operate video playback software
ITEM | PARAMETER | 4CH 720P HDD SSD MDVR |
System | Language | English |
Operation System | Linux | |
Interface | Imaging menu operation interface (OSD Menu) | |
Password Security | Two levels authority: admin, user | |
Video | Video Input | 4CH 720P 960P AHD Camera |
Video Output | 1 composite video & 1 VGA outputs | |
Video standard | PAL, NTSC | |
Video compression | H.264 Main profile, 100 frame / sec | |
Video Display | Single/Quad screen video | |
Audio | Audio Input | 4 audio input |
Audio Output | 1 audio output | |
Audio Code | G726 | |
Way of recording | Simultaneous AV recording | |
Image Processing & Storage | Image format | CIF/HD1/D1/720p optional |
Standard of Video Stream | ISO14496-10 | |
Video code rate | CIF: 1536Kbps ~ 128Kbps, | |
HD1: 2048Kbps ~ 380Kbps, | ||
D1: 2048Kbps ~ 400Kbps, | ||
720p: 2048Kbps ~ 4096Kbps, | ||
1080P: 2048kbps~8192kbps | ||
Image quality: Grade 1(best quality) - 8(worst) | ||
Audio Code Rate | 40KB/s | |
Data Storage | Support 1x 2TB HDD & 1x 128GB SD storage | |
Alarm | Alarm input | 8x Alarm input |
Alarm output | 2x Alarm output, with 12V high electrical level | |
Communication Port | RS232 port | 2x RS232 |
RS485 port | 2x RS485 | |
RJ45 Port | 1x 10M/100M auto adjust Ethernet port | |
Extendable Port | Intercom | support |
Speed pulse | External connect | |
Others | LED panel | |
Wireless Modules | 3G WCDMA | optional |
4G LTE | Optional, support TD-LTE/FDD-LTE | |
WIFI | Optional, 802.11b/g/n | |
GPS | Optional, embedded module, show Geo-location, speed etc. Wireless upload function (Optional) | |
Acceleration sensor | G-sensor | Built-in |
Software | Vehicle Network Management System (VNMS / CMS) | 3G video monitoring and GPS tracking etc. PC/ Web/Android/iPhone/iPad platforms, multi-languages. |
Vehicle Analysis Software (VAS) | Video playback and analysis | |
Parameter | Instruction | |
+8V~+36V | Voltage Input:+8V~+36V Power will be auto off to self-protection activated if device is out of this range for long time, | |
12V | Voltage output 12V (+/-0.2V 0), current for max. 4A | |
≤6V | ACC Off | |
≥7.5V | ACC On | |
75Ω | Average 75Ω per video channel | |
2V p-p | 75Ω per each 2V p-p CVBS signal | |
0-4V | Defined as low level alarm | |
> 4V | Defined as high level alarm | |
1x HDD slots 1x SD slots | HDD (Hard Disk) of 2.5” SATA, 2TB max. SD card of current brands, 128GB max. SD card can be used for recording, upgrade etc. | |
-20°C~+80°C | Temperature in well ventilated condition |
